Project NERO

Project Nero was Portal Space's focus from 2020 to 2022 - building and launching Norway's first liquid-fueled rocket

The project NERO started in February 2020. We wanted to create Norway's first liquid-fueled rocket. After a year of building the organization, designing and manufacturing, the first successful hot-fire was achieved on July 17th, 2021.

We planned to compete in the European Rocketry Challenge in 2022. EuRoC is the first university rocket launch competition in Europe and is held in Ponte de Sor in Portugal. We will compete in the class of liquid-fueled engines with a 9 km flight. Unfortunately, we had to cancel our plans since the rocket was not ready.

36ae1a_58258aad2f054f36a24285395c68fbde~mv2.avif

The Rocket Design

Height: 5.5m

Dry mass: 100kg

Fins: #3

Diameter: 240mm

Material Skeleton: Aluminium

Material Shell: Carbon Fiber

The engine Reodor MK1

Thrust: 3500N

Mass Flow Rate: 1.47 kg/s

Specific Impulse: 245s

Oxidizer - Fuel Ratio: 1.33

Combustion Chamber Pressure: 20 bar

Test Specifications from 17.07.2021

Average Thrust: ~2400N

Average Chamber Pressure: ~19 bar

83eaf3_a20579deadd44d41be2747c315978c36~mv2.avif

Our engine is named after the character Reodor Felgen from the classical Norwegian movie Flåklypa Grand Prix.

The vehicle he creates, Il Tempo Gigante, includes two liquid-fueled rocket engines which run on ethanol. The movie is also set in a rural part of Norway, and we found the name suitable since we started our manufacturing at a farm.

Fun fact

36ae1a_0a877493ca0f48ca85e88f9ab69a7fcd~mv2.avif

The engine Reodor MK2

Thrust: 5000N

Mass Flow Rate: 2.3 kg/s

Specific Impulse: 224s

Oxidizer - Fuel Ratio: 1.33

Combustion Chamber Pressure: 20 bar

Test Specifications from 28.05.2022

Average Thrust: ~2900N

Average Chamber Pressure: ~18 bar
